THE MOST AGGRESSIVE SHAPE OF ALL DOSNOVENTA® FRAMES. THANKS TO ITS PURSUIT GEOMETRY, IT WILL TAKE YOU TO THE NEXT LEVEL. COMPETITIVE, FAST, LIGHT, STIFF, REACTIVE AND VERY UNIQUE. SINCE 2012, THE DETROIT FRAME HAS BEEN THE CHOICE OF MANY PRO RIDERS AROUND THE WORLD.

COLOR ARMY ORANGE MATT
FRAME COLUMBUS AIRPLANE TUBING . 7005-T6 TRIPLE BUTTED ALLOY
FORK FULL CARBON FORK . TAPERED 1-1/8” . RAKE 45MM . 700X28C MAX
HEADSET (included) COLUMBUS COMPASS . 1-1/8" CARBON
BB BSA 68MM
SEAT TUBE 27.2 Ø
GROUND CLEARANCE 290MM
TIRE CLEARANCE 700X28C MAX
FRAME WEIGHT 1450 GR (M SIZE)
FORK WEIGHT 410 GR

DOSNOVENTA®03 DET / ORANGE FRAMESET

THE DETROIT, THE MOST AGGRESSIVE SHAPE OF DOSNOVENTA. COMPETITIVE, FAST, LIGHT, STIFF, REACTIVE AND VERY UNIQUE

$1,190.00

Select Size S M L Add to cart
SEE SIZE GUIDE
S M L
RIDER HEIGHT 154CM - 170CM 171CM - 182CM 183CM - 192CM
Seat Tube (Center to Center) 470 510 550
Seat Tube (Center to Top) 510 550 590
Head tube length 90 110 140
Effective top tube length 505 530 565
Head tube Angle 74 74 74
Seat tube angle 76 76 76
Stack (mm) 468 487 516
Reach (mm) 388 408 436
BB Drop 41 41 41
Chainstay Length 382 382 382
Bottom Braket 290 290 290
